Professional heating solutions backed by European engineering.

MASTER forced air diesel heaters deliver dependable, high-capacity heating for commercial, industrial, and agricultural environments.

• Powerful heat output ranging from 20 kW to over 44 kW
• Rugged construction with stainless steel combustion chambers for long service life
• Integrated safety features including flame detection and overheat protection
• Easy maintenance access and portable designs with built-in wheels and handles (B100, B150)

Features

• High air flow
• Two oil filters – oil tank filter and suction filter
• Thermally protected motor
• Electronic flame control with photocell
• Stainless steel combustion chamber
• Oil tank with level indicator
• Designed for easy handling and transportation
• Easy maintenance
• Suitable for:
  • Agriculture
  • Automotive
  • Buildings and commercial spaces
  • Construction
  • General industry and production
  • Military and aerospace
  • Rental companies

Specifications

• Select model:
  • B 35
  • B 70
  • B 100
  • B 150
  • B 300
• Units: B 70
• Heating power: 20 kW
• Heating power: 68,300 Btu/h
• Heating power: 17,200 kcal/h
• Air flow: 400 m³/h
• Fuel autonomy: 10 h
• Thermostat control: Analogue or digital
• Fuel consumption: 1.9 L/h
• Power supply: 220/240/50-60 V/Hz
• Electric power: 0.18 kW
• Rated current: 0.8 A
• Protection: IP41
• Tank capacity: 19 L
• Product size (L x W x H): 745 mm x 300 mm x 405 mm
• Box size (L x W x H): 810 mm x 350 mm x 450 mm
• Net/Gross weight: 15/18 kg
• Pallet: 15 pcs
• Dual voltage: No
